PARTS LIST
MODEL NO.: CH8136SQ
NO. DESCRIPTION MODEL /SIZE PART NO.
1 Duct Cover CH81SDC 90A-1-0001
2 7” Round Adapter 90A-2-0002
3 Duct Cover Position Plate 90A-3-0003
4 Exhaust Duct Stand 90A-4-0004
5 Side Trim (Right) 90A-5-2005
6 Side Trim (Left) 90A-5-1005
7 Front Trim 90A-6-0006
8 Hood Casing 90A-7-0007
9 Control Unit 90A-8-0008
10 Halogen Light (12V 20W Max.) 90A-9-0009
11 Wire Box 90A-10-0010
12 Capacitor 90A-11-0011
13 Center Position Panel 90A-12-0012
14 Air Chamber 90A-13-0013
15 Motor (Left) 90A-14-1014
16 Motor (Right) 90A-14-2014
17 Turbine Impeller (Left) 90A-15-1015
18 Turbine Impeller (Right) 90A-15-2015
19 Oil Tunnel 90A-16-0016
20 Impeller Plastic Cover 90A-17-0017
21 Safety Screen 90A-18-0018
22 Oil Container (Round) 90A-19-0019
23 Bottom Casing 90A-20-0020
24 Oil Container (Oval) 90A-21-0021
25 Transformer (Light) 90A-22-0022
26 Duct Cover Bracket 90A-23-0023
27 Hood-Mounting Bracket 90A-24-0024
