Description of the appliance, Overall view, Control panel – Hotpoint Ariston LL 40 User Manual
Page 4
4
EN
Overall view
1.
Upper rack
2.
Upper sprayer arm
3.
Tip-up compartments
4.
Rack height adjuster
5.
Lower rack
6.
Lower sprayer arm
7.
Cutlery basket
8.
Washing filter
9.
Salt dispenser
10.
Detergent and rinse aid dispensers
11.
Data plate
12. Control panel***
*** Only total built-in models
* Only available in selected models.
Description of the appliance
Control panel
ON-OFF
indicator light
ON-OFF
button
WASH CYCLE PHASE
indicator lights
PRE-WASH
WASH
DRYING
RINSES
WASH CYCLE
indicator light
WASH CYCLE
SELECT
button
LOW SALT
indicator light*
START/RESET
button
