16
PARTS LIST
MODEL NO.: RA3830S
RA3836S
(Optional Duct Cover)
NO. DESCRIPTION MODEL /SIZE PART NO.
1 6” Round Plastic Exhaust C1-0505-0001
2 Capacitor C1-0401-0120-01A
3 Transformer (Motor) C1-0402-0120-40
4 Screw (4 x 6 mm) C1-0708-0001
5 Screw (4 x 6 mm) C1-0708-0001
6 Power Cord C1-0406-0120
7 Screw (TS 4 x 18 mm) C1-0708-0004
8 Plastic Plate C1-0507-0201
RA3830S 10-03300 9 Hood Casing
RA3836S 10-03360
10 Screw (3/16” x 5/8”) C1-0704-0004
11 Halogen Light (12V 20W Max.) C1-0403-0101
Air Chamber
RA3830S Air Chamber (Top)
RA3836S
C1-0101-0382
RA3830S
12
A
B Air Chamber (Side)
RA3836S
C1-0102-0382
13 Motor (Left) C1-0301-0120-13A
14 Motor (Right) C1-0301-0120-14A
15 Turbine Impeller (Left) C1-0251-0092-01
16 Turbine Impeller (Right) C1-0251-0092-02
17 Oil Tunnel Seal C1-0502-0301
18 Oil Tunnel C1-0502-0203
RA3830S B101-0330-09 19 Bottom Casing
RA3836S B101-0392-09
20 Oil Container (Oval) C1-0504-0101
21 Safety Screen C1-0602-0101
22 Oil Container (Round) C1-0503-0101
23 Safety Screen Screw C1-0705-0001
24 Screw (3/16” x 5/8”) C1-0704-0004
25 Impeller Plastic Cover C1-0251-0001
26 On/Off Switch C1-0405-0211
27 Speed Switch C1-0405-0212
28 Light Switch C1-0405-0213
NO. DESCRIPTION MODEL /SIZE PART NO.
29 Rubber Stand C1-0511-0211
30 Screw (TS 4 x 8 mm) C1-0708-0006
31 Screw (3/16” x 3/8”) C1-0707-0001
32 Hood-Mounting Bracket C1-0221-0330
33 Duct Cover RA1020DC 12-02000-430
34 Round Head Screw (TS 4 x 8 mm) C1-0708-0006
35 Round Head Screw (TS 4 x 8 mm) C1-0708-0006
36 Duct Cover-Mounting Bracket C1-0203-0002
