AlphaServer 8400
3.230 Alpha Servers
UPS Solutions
For complete protection, UPS products should be used with data line surge protectors. See TVSS section of Environmental
Products Chapter.
4N-GA249-AB
2 wire modem
wall plug in
4N-GA249-CA
10BaseT
wall plug in
4N-GA510-BF
ThinWire
device port
4N-GA245-xx
Din rail and modules
up to 32 ports
Receptacle Module for Plug-in Connection
UPS Model
60 HZ
50 HZ
AlphaServer 8400
External Storage
4N-AEAAL-BA
4N-AEACK-BN
Hardwired
Single phase
None, SW500, or Expansion Cabinet
4N-AEAAN-BA (60 Hz)
4N-AEAAN-BE (50 Hz)
4N-AEACM-BN
Hardwired
Single phase
SW800
4N-AEAAN-BA (60 Hz)
4N-AEAAN-BE (50 Hz)
4N-AEACM-BK
Hardwired
Three Phase
None
4N-AEAAN-BA (60 Hz)
4N-AEAAN-BE (50 Hz)
4N-AEACM-PA
Hardwired
Three Phase
SW800 or Expansion Cabinet
UPS Models
4N-AEAAL-BA
PUPS plus 10kVA (7kW), single-phase, 50/60Hz, 176-276V in, 200-240V out, 9 minutes battery at full load;
hardwired with optional plug-in output receptacle modules.
4N-AEAAN-BA
PUPS plus 15kVA (10kW), three-phase, 50/60Hz, 176-256V in, 200-240V out, 10 minutes battery at full load;
hardwired with optional plug-in output receptacle modules.
4N-AEAAN-BE
PUPS plus 15kVA (10kW), three-phase, 50/60Hz, International model rated 380/415V in, 380/415/220V out;
hardwired input/output.
Options
4N-AEACK-BN
PUPS plus 10kVA receptacle module (3) L6-30R, (3) 5-20R2, (2) L5-20R
4N-AEACM-BK
PUPS plus 15kVA receptacle module (2) L21-30R, (3) 5-20R2
4N-AEACM-BN
PUPS plus 15kVA receptacle module (2) L6-30R, (2) L21-30R, (1) 5-20R2
4N-AEACM-PA
PUPS plus 15kVA dual receptacle module:
Module 1: (2) L21-30R and conduit kit for connecting Module 1 to Module 2
Module 2: (2) L21-30R, (3) 5-20R2
UPS Monitoring and Unattended Shutdown Software (for above UPS systems only)
Note: Power Management software is included in ServerWORKS Manager kits shipping with all AlphaServers. Cable kit
required, select UPS Communications Cable Kit
DIGITAL UNIX
1
OpenVMS
4N-ONLIN-NT
1
4N-ONLIS-FE
UPS Communications Cable Kit
4N-AEAEO-Dx
2
4N-JMIU4-AB
3
4 port
Hardware Option for multi-systems on one UPS
4N-AEAEO-Dx
2
4N-AEAEO-Dx
2
Option for SNMP/ ServerWORKS Manager interface
Ala Carte Software kits available for existing installations
DIGITAL UNIX
1
OpenVMS
4N-AEAES-AK
4N-AEAES-EM
Prestige (single system)
4N-AEAES-AK
4N-AEAES-FM
PUPS Plus (single system)
4N-AEAES-BK
4N-JMMCR-AA
4
2 port
4N-JMIU4-AA 4
port
4N-JMIU8-AA
8 port
Multi-systems on one UPS
4N-AEAEO-Dx
4N-AEAEO-Dx
Network Monitoring
1. Connect-UPS network adapter required for operation on AlphaServer 8400 DIGITAL UNIX systems. See footnote 2.
2. Connect-UPS network adapter; D* denotes Twisted Pair / ThinWire = DA/DC (60Hz; 120V NEMA); DB/DD (50Hz: 240V IEC)
3. Multi-port interface kit with splitter cable to interface with network adapter and local shutdown signal from UPS. Kits may be daisy
chained, kits include software
4. Same as 3 above except 2 port for basic shutdown and one smart monitoring port
