Page 18

SPECIFICATIONS

Voltage

120V

60 Hz

Rated Current

6.6 A

No-Load Speed (motor)

1725 RPM

Max. Distance
From Spindle Axis
To Surface Of Column:

6 5/8" (170.275mm)

Max. Distance
From Spindle End
To Surface Of Table:

30 3/4" (781.050mm)

Spindle Travel:

3 1/8" (79.375mm)

Chuck Capacity

5/8" (15.875mm)

Range of Spindle Speeds

210-3840 RPM

Laser Beam

Class II, Diode Laser

Average Radiant Power

1mw

Laser Beam Wavelength

650nm

OTHER CONSUMER DO-IT-YOURSELF (DIY) TOOLS

Alltrade offers a full range of Kawasaki™ tools that make DIY jobs easy. If you would
like further information on the following products, please contact Alltrade Customer
Service Department at 1-800-590-3723.

Cordless Drills/Screwdrivers

Impact Wrenches

Sanders

Jigsaws

Circular Saws

Angle Grinders

Reciprocating Saws

Routers

Rotary Tools

Corded and Cordless Multi-Purpose Tools

Wide Range of Accessories and more

TROUBLESHOOTING

To avoid any accidental starting of the Drill Press, turn

the switch to the “OFF” position, remove the safety key, and unplug the tool
from the AC power source.

Should the motor fail to run, for any reason, call Alltrade Customer Service.

ACCESSORIES

Optional accessories for the drill press can include wire-brush wheels that can be
used for cleaning and layered cloth wheels that can be used for polishing and buff-
ing. Contact ALLTRADE Customer Service at 1-800-590-3723 (toll free) to find out
what accessories are available for the drill press.

Only use accessories that are designed to fit your partic-

ular drill press. These accessories should be specifically labeled to match
the speed and arbor size of the grinder. Failure to use the proper accessories
could result in property damage, damage to the grinder, and serious person-
al injury to the operator.

Always attach grounded (3-prong) extension cords to grounded (3-hole) outlets.

If the drill press must be used outside, use an extension cord labeled “W-A” or
“W.” These extension cords are rated for outdoor use and reduce the chances of
electrical shock.

If you must use an extension cord, be sure that the gauge is large enough to carry
the amount of current necessary for your power tool. If not, your tool may experi-
ence a loss of power, excessive voltage drop or overheating. The smaller the gauge
number, the heavier the cord (see table below).

RECOMMENDED SIZES OF EXTENSION CORDS 120 VOLT AC 60 HZ TOOLS

TOOL CURRENT RATING

CONDUCTOR SIZE IN A.W.G

AMPERE

10FT.

25FT.

50FT.

100FT.

3-6

6-8

8-10

10-12

12-16

16-20
