REFRIGERATOR LINER PARTS

4

For Models: KBLS22KTSS11

(Stainless Steel−LH)

W10183698

Illus. Part

No. No. DESCRIPTION

1

Liner (Not A

Serviceable Part)

2

Y67003896 Bracket, Control

and Lights

3 W10183186 Overlay
4

67005444 Housing,

Electronic Control

5

67005397 Electronic Control

6

C3680310 Switch, Light

7

67003897 Cover, Light

8

67003901 Housing, Light

9

A0282812 Bulb, Light (2)

10

Y12570701 Socket, Light (2)

11

67003900 Insert,

Damper Cover

12

67006602 Screw

13

67003899 Cover, Damper

14

67006604 Insulation

15 W10127429 Control, Damper
16

12002355 Thermistor

Following Parts Not Illustrated

67005644 Harness, Controls

(Refrigerator)
(Includes # 16)
