G.

Sharp blades can cause bodily injury if not handled properly.

pened.


Out of b
bolts co

CAUTION: Always properly tighten the blade bolts to the specified torque. Failure to do so
can lead to

saddle.

The Models MR55K, MR55B and MR55T use the Kunz Engineering Part # (202141) blade bolt.
This particular hex head bolt is a 3/4” – 16NF x 1-1/4” long, grade 5 and it’s proper torque is 300
ft-lbs.

To ease in the blade installation process, use the same block of wood and method used during
the removal of the blades


H. LUBRICATION

There are five lubrication points on the rough cut mower -- one spring-loaded idler pivot, two
caster wheel pivots, and two blade spindles. Lubricate at approximately 10 hr. intervals or more
often as required in dusty conditions. Lubricate the blade spindles 2-5 pumps every 50 hours.
(The bearings have trash guard seals to hold the seals in place during lubrication.) Lubricate with
a high grade of pressure gun grease.


Note: Do not over grease blade spindles. Blade spindles are initially greased at the factory.

Greasing before 50 hrs. may cause bearing seal damage which will result in premature
bearing failure.

I. STORAGE

Turn off

wer is

stored o

ne

during h

MOWER BLADE REMOVAL, BALANCING & INSTALLATION

CAUTION:

When removing the blade, it is recommended that a block of wood be placed between the blade
and the underside of the mower deck. This will allow the removal of the blade without the need to
hold the blade by hand.


CAUTION:
Always balance the mower blades each time they are shar

alance mower blades cause excess vibrations which lead to premature bearing failures,

ming loose, and overall deterioration of the wing mowers.

unwanted loosening of the blade and damage to the blade holding

.

fuel shut off valve which is located on the underside of the gas tank. If the mo

utside, the engine should be covered to prevent water from getting inside the engi
eavy rainstorms. See the Engine Manual for additional information.

13
