WASH CYCLE
SELECTOR knob
Button with ON/OFF
indicator light
Touch control panel
Button with ON/OFF indicator light: press this briefly
to switch the machine on or off. The green indicator light
indicates that the machine is switched on. To switch off the
washing machine during the wash cycle, press and hold the
button for approximately 3 seconds; if the button is pressed
briefly or accidentally the machine will not switch off. If the
machine is switched off during a wash cycle, this wash cycle
will be cancelled.
WASH CYCLE SELECTOR knob: may be turned in either
direction. To select the most suitable wash cycle, please refer
to the “Table of wash cycles”.
The knob will not move during the wash cycle.
M1-M2-M3 buttons: press and hold one of the buttons to
store a cycle with your own set preferences in the memory
of the machine. To recall a previously-stored cycle, press the
corresponding button.
TEMPERATURE button: press to modify or exclude the
temperature setting; the value selected will appear on the
display above (see “Running a wash cycle”).
SPIN CYCLE button: press to modify or exclude the spin
cycle; the value selected will appear on the display above (see
“Running a wash cycle”).
DELAYED START button: press to set a delayed start for
the selected wash cycle; the set delay time will appear on the
display above (see “Running a wash cycle”).
OPTION buttons: press to select the available options. The
indicator light corresponding to the selected option will remain
lit (see “Running a wash cycle”).
WASH CYCLE PHASE icons: these illuminate to indicate the
progress of the wash cycle (Wash
– Rinse – Spin
– Drain ). The text lights up when the cycle is complete.
START/PAUSE button with indicator light: when the green
indicator light flashes slowly, press the button to start a wash
cycle. Once the cycle has begun the indicator light will remain
lit in a fixed manner. To pause the wash cycle, press the button
again; the indicator light will flash in an orange colour. If the
“Door locked” indicator light is switched off, the door may
be opened. To start the wash cycle from the point at which it
was interrupted, press the button again.
DOOR LOCKED indicator light: indicates that the
porthole door is locked. To open the door, pause the wash
cycle (see “Running a wash cycle”).
CONTROL PANEL LOCK button with indicator light: to
activate or deactivate the control panel lock, press and hold
the button for approximately 2 seconds. when the indicator
light is illuminated, the control panel is locked. This means
it is possible to prevent wash cycles from being modified
accidentally, especially where there are children in the home.
ECO indicator light: the icon lights up when, after altering
the washing parameters, an energy saving of at least 10%
is made. Furthermore, before the machine enters “Standby”
mode, the icon will light up for a few seconds; when the
machine is switched off the estimated energy saving will be
around the 80% mark.
CHANGE LANGUAGE
The first time the machine is switched on, the first language
will flash on the display. The “ “, “OK” and “V” symbols will
appear on the display, in line with the 3 buttons on the right-
hand side. The languages change automatically every 3”;
alternatively, they can be changed by pressing the buttons
next to the “ “ and “V” symbols. Use the “OK” button to
confirm the language, which will be set after 2”. If no buttons
are pressed, the automatic language change will begin again
after 30”.
The language may only be changed while the machine is
switched off.
Press and hold the temperature
+spin +delayed start
buttons for 5’’; a short beep sounds and the set language
flashes on the display. Press the buttons next to the “ “ and
“V” symbols to change the language. Use the button next to
the “OK” symbol to confirm the language, which will be set
after 2”. If no buttons are pressed, the language set previously
will be displayed after 30”.
Switch on the machine.
TEMPERATURE
button
OPTION
buttons
SPIN
button
DISPLAY
M1
ECO
indicator light
DELAYED START
button
START/PAUSE button
with indicator light
DOOR LOCKED indicator light
WASH
CYCLE
PHASE
icons
CONTROL PANEL
LOCK
button with
indicator light
M2
M3
