ENGLISH
34
TECHNICAL SPECIFICATIONS – CHASSIS 85/105 SX 2007
»
CHASSIS 85 SX (17”/14”) 85/105 SX (19”/16”)
Frame Central chrome-moly-steel frame
Fork telescopic fork WP Suspension 4357 MXMA
Wheel travel front/rear 275 mm / 300 mm (10.82/11.81 in)
Rear suspension WP PDS 4618 (Progressive Damping System) shock absorber
Front brake Disc brake Ø 220 mm (8.66 in), 4 piston
Rear brake Disc brake Ø 200 mm (7.87 in), 4 piston
Tires front 70/100-17“ Pirelli NHS 40 M 70/100-19“ Pirelli NHS 42M
Tires rear 90/100-14“ Pirelli NHS 49 90/100-16“ Pirelli NHS 51
Air pressure 1.0 bar
Fuel tank capacity 5.1 liter
Final drive ratio 14 : 46 t 14 : 49 t
Chain 1/2 x 5/16" 122 rolls
Steering angle 66 °
Wheel base 1290 mm
Seat height, unloaded 865 mm 900 mm
Ground clearance 385 mm 415 mm
Dead weight without fuel 66 kg 68 kg
Rider’s body weight max. 75 kg
Recommended age of rider 10 to 15 years
Engine CR-85
STANDARD ADJUSTMENT – FORK
WP 4357 MXMA
05187C05
Compression adjuster 20
Rebound adjuster 20
Spring 3 N/mm
Spring preload 3 mm
Air chamber length 110 mm
Fork oil SAE 5
STANDARD ADJUSTMENT - SHOCK ABSORBER
WP 4618 PDS-DCC
WP 15187C02
Compression adjuster
15 LS (
LOW SPEED
)
2 HS ( HIGH SPEED )
Rebound adjuster 22
Spring 35-215
Spring preload 7 MM
TIGHTENING TORQUES - CHASSIS
Hexagon bolt - brake caliper front
M 8 Loctite 243 + 25 Nm
Allan head screw - brake pads rear M6 5 Nm
Flat head bolt - brake discs M6 Loctite 243 + 14 Nm
Hexagon nut - front wheel spindle M 10x 1.5 40 Nm
Hexagon nut - rear wheel spindle M 20x1.5 80 Nm
Hexagon nut - swingarm bolt M 14/M 16x1.5 75 Nm
Clamping bolts - top triple clamp M 8 20 Nm
Clamping bolts - bottom triple clamp M 8 15 Nm
Bolt - handlebar clamp M 8 20 Nm
Spoke nipple M 4,5 5.0 Nm
Other chassis bolts
M6
M8
M10 10 Nm
25 Nm
45 Nm
