16
PARTS LIST
MODEL NO.: RA0230SQB
RA0236SQB
RA0242SQB
RA0248SQB
NO. DESCRIPTION MODEL /SIZE PART NO.
1 Ducting Transition FA-12001-0506-01 (B001-2)
2 Duct Cover RA02DC 12-56000-012-51
3 Mounting Bracket C1-0221-0092
RA0230SQB 10-5630B-51
RA0236SQB 10-5636B-51
RA0242SQB 10-5642B-51
4 Hood Casing
RA0248SQB 10-5648B-51
5 Halogen Light Unit (12V 20W Max.) C1-0403-0101
6 Motor FA-12001-0302-01 (B001-4.5)
7
LCD Panel Box
LCD Panel
LCD002
FA-12002-0404-A
FA-12002-0404-B
8 Capacitor FA-12001-0401-01
9 Safety Screen FA-12001-0602-01 (B001-4.2)
10
Processor Board Box
Processor Board
LCD002
C1-0501-0102
FA-12002-0404-C
RA0230SQB
RA0236SQB
C1-0402-0120-40B
RA0242SQB
11 Transformer Light
RA0248SQB
C1-0402-0120-60B
RA0230SQB C1-0201-5630
RA0236SQB C1-0201-5636
RA0242SQB C1-0201-5642
12 Capacitor Panel
RA0248SQB C1-0201-5648
13 ISC (Integrated Sensor Control) FA-12001-0402
RA0230SQB B101-5630-14
RA0236SQB B101-5636-14
RA0242SQB B101-5642-14
14 Oil Tunnel
RA0248SQB B101-5648-14
15 Baffle Filter B101-1930-15
RA0230SQB B101-5630-09
RA0236SQB B101-5636-09
RA0242SQB B101-5642-09
16 Bottom Casing
RA0248SQB B101-5648-09
BLOWER ASSEMBLY
NO. DESCRIPTION MODEL /SIZE PART NO.
6-1 Screws (3/16” x 1/2”) B001-4.1
6-2 Left Locknut B001-4.3
6-3 Left Squirrel Cage B001-4.4
6-4 Right Squirrel Cage B001-4.6
6-5 Right Locknut B001-4.7
6-6 Air Chamber B001-4.8
