UNIT PARTS
10
For Models: KBFS20EVWH00, KBFS20EVBL00, KBFS20EVMS00
(White) (Black) (Monochromatic Stainless)
W10210877
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
67006433 Screw
2 W10156818 Blade, Fan
3
67005889 Basepan
4
67006425 Screw
5
67004954 Screw
6 W10134623 Compressor
7 W10171661 Harness, Evap.
Heater
8
67007175 Drain Pan
9
61004743 Grommet (3)
10
67002493 Heater, Defrost
11
2264017 Capacitor
12 W10128795 Start Device
13
61003210 Gasket
14 W10165425 Thermostat,
Defrost
15 W10137529 Grommet (4)
16
12575309 Shroud, Condenser
17
2255199 Clip, Capacitor
18
67006131 Condenser
19 W10134293 Tube, Discharge
20
67002490 Tray, Drip
21
10623002 Clip, Evaporator
22
67003720 Evaporator
23
Dam
67001084 Right Side
67001083 Left Side
24
67004432 Motor, Fan
25
10428101 Clip, Heater
26
13060202 Harness, Unit
with Power Cord
27 W10143759 Drier
28
10547003 Clip, Drier
29
67004953 Bracket, Condenser
30 W10169124 Grommet
31
67006432 Screw (3)
32
67006573 Screw
33
67005421 Cover, HV
34 W10205114 Board, HV
35
67005418 Spacer, HV
36
67004969 Box, HV
37
67006550 Screw
38
12972902 Harness, HV
39
67006615 Screw (3)
40
67006737 Screw
41
67005680 Grommet (2)
42
67005491 Block, Condenser
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.0 Ozs.
(R−134A)
