Keys Fitness ALL800 - Manual (Page 19)

Part #
1 L e f t S i d e E x t r u s i o n R a i l 0 5 - 0 0 3 6
2 R i g h t S i d e E x t r u s i o n R a i l 0 5 - 0 0 3 6
3 T r e a d m i l l B e l t 0 4 - 0 0 2 5
4 F r o n t R o l l e r A s s e m b l y 2 4 - 0 2 1 8
5 R e a r R o l l e r 0 9 - 0 0 1 3
6 T r e a d m i l l D e c k 0 3 - 0 0 1 1
7 E n d C a p ( L / R ) 0 6 - 0 0 0 8
8 E l e v a t i o n M o t o r ( a c t u a t o r ) 1 2 - 0 0 2 2
9 P a n - M o t o r B a s e 0 6 - 0 0 1 8
P a n - C e n t e r B a s e 0 6 - 0 0 1 9
P a n - E n d B a s e 0 6 - 0 0 2 0
1 0 S m a l l F a n 0 6 - 0 0 8 0
1 1 M o t o r 1 2 - 0 0 2 3
1 2 P o l y V B e l t 0 4 - 0 0 0 4
1 3 M o t o r H o o d C o v e r To p 0 6 - 0 1 0 5
19
Please review the following drawing below to familiarize yourself with the listed parts. This man-
ual covers several treadmills, so the one pictured below may not be identical to your particular
model.
Parts & Diagrams
