EVAPORATOR, ICE CUTTER GRID AND WATER PARTS
4
For Model: KUIC15NRSS0
(Stainless Steel)
8214978
Illus. Part
No. No. DESCRIPTION
1 2313644 Valve, Complete
Water
2 2217286 Tube, Plastic
3 488208 Screw
4 2185523 Dispenser, Water
5 2217269 Evaporator
8 2172593 Tube, Water Fill
9 488660 Nut, Speed
10 836667 Spacer
11 2208539 Fastener,
Pushnut
12 489443 Screw
13 2185625 Reservoir,
Water Slide
14 2185626 Tube
15 2185673 Hose, Overflow
16 2313604 Guide−Ice, Grid
17 2313603 Bracket, Front
and Rear
18 2313602 Bracket, Side
Left and Right
19 2185681 Harness, Grid
20 2313745 Tube
26 3400886 Screw
28 2313637 Grid Assembly
(Complete)
29 2174754 Wire, Grid Cutter
30 2185570 Cover, Grid
31 8281228 Thumbscrew
32 2217379 Reservoir, Water
33 3400884 Screw
34 2185696 Cap, Drain
35 3400909 Nut, Push−In
