Assembly
6
Right Fender
Left Fender
Left Upright
Right Upright
Left Fender
Left Upright
Console Harness
Figure 1
Step 1
Place the left and right
uprights tube through the holes
in the left and right fenders.
Figure 1
Figure 2 Figure 2
Step 1
Slide the fenders up the
upright assembly and pull
the console harness through
the hole in bottom of the left
upright tube.
Assembly requires the included Allen wrench.
Do not plug in the power cord until all assembly steps are completed.
