Exploded drawing, Parts list – Keys Fitness 4'DUMBBELL RACK ST-DB4 User Manual
Page 3
3
EXPLODED DRAWING
PARTS LIST
Part
no.
Description
Qty.
Remarks
1
Left Main Body Frame
1
2
Right Main Body Frame
1
3 Rack
Support
6
4 Base
frame
2
5
2” Sq. End Outer Cap
4
Pre-assembled
6
1 3/4”Sq, Inner Plug
12
Pre-assembled
7 2”Sq,
Inner
Plug
2 Pre-assembled
A1
Hex Head Bolt M10X65
16
B1 Washer
Ø
10
32
C1 Aircraft
Nut
16
