14
PARTS LIST
MODEL NO.: IS2136SQB
IS2142SQB
NO. DESCRIPTION MODEL /SIZE PART NO.
1 Ducting Transition FA-12001-0506-01 (B001-2)
IS2136SQB B101-5436-02 2 Hood Casing
IS2142SQB B101-5442-02
3 Halogen Light Unit (12V 20W Max.) C1-0403-0101
4 Valve Stem C1-0405-0404-B
5 Control Frame C1-0207-5200-A
6 Motor FA-12001-0302-01 (B001-4.5)
IS2136SQB C1-0201-5436 7 Capacitor Panel
IS2142SQB C1-0201-5442
8 Knob C1-0405-0400-A
9 Capacitor FA-12001-0401-01
10 Transformer Light C1-0402-0120-80A
11 Support Frame C1-0203-5400-12A
12 Duct Cover IS21DC 12-54000-012-51
13 Baffle Filter B101-5400-15
14 Bottom Casing B101-5442-09
BLOWER ASSEMBLY
NO. DESCRIPTION MODEL /SIZE PART NO.
6-1 Screws (3/16” x 1/2”) B001-4.1
6-2 Left Locknut B001-4.3
6-3 Left Squirrel Cage B001-4.4
6-4 Right Squirrel Cage B001-4.6
6-5 Right Locknut B001-4.7
6-6 Air Chamber B001-4.8
6-7 Safety Screen FA-12001-0602-01 (B001-4.2)
