Kustom KXB10 User Manual
Page 8
Kustom
®
KXB10 Specifications
Output Power
10 Watts
4 Ohms at 10% THD+N
Speaker
1 X 10”
Custom Designed 4 Ohms
Input Impedance
Single Input
470K Ohm
Gain
48 dB
Volume @ Max, All EQ at 12 o’clock
S/N Ratio
-80 dB typical
Below rated power
Aux Input
800 mV Sensitivity
Stereo 3.5mm High Impedance
Headphone Output
10 mW @ 30 ohms
per channel
Stereo 3.5mm
Amplifier Tone Controls
60 Hz
+/- 15 dB
500 Hz
+/- 15 dB
10 Hz
+/- 15 dB
Power Requirements
USA/Canada
120VAC/60Hz, 25W
Europe
230VAC/50Hz, 25W
UK
240VAC/50Hz, 25W
Australia
240VAC/50Hz, 25W
Japan
100VAC/50-60Hz, 25W
Dimensions/Weight
cm
3
/Kilogram
44.5 (Height) X 35.1 (Width) X 26.4 (Depth),
10.4 Kilogram
Inches/Pounds
17.5 (Height) X 13.8 (Width) X 10.4 (Depth),
23 Lbs
kustom.com
