7
KF-lEGA Parts list Rev A
Ref # Part # description Qty
1 223-00960 LEG LIFT, KF-LEGA 1
2 219-00587 ROLLER TUBE, KF-LEGA 2
3 223-00961 LEG SUPPORT, KF-LEGA 1
4 206-00138 ROUND PLUG 25 1
5 206-00395 FOAM PADDING, 100X22X180 KF SERIES 4
6 206-00279 SQUARE END CAP, KPS-LEGA 3
7 202-00092 NYLON NUT, M12 1
8 202-00222 WASHER, 13X26X2 KPSFI #32 2
9 202-00640 SCREW, M12X80 BUTTON HEAD SOCKET CAP 1
10 206-00187 BUMPER 1
11 210-00146 U PIN, KPS-HCL, KPS-LEGA, KPS-OB 1
12 206-00390 PLUG, ROLLER PAD TUBE CAP, KF SERIES 4
13 219-00008 SPRING COLLAR 1
14 219-00326 SPRING COLLAR PLASTIC GRIPS 1
# 202-00681 BOLT PACK, KF-LEGA 1
Parts list
