background image

KDC-C717

KDC-C667

COMPACT DISC AUTO CHANGER

INSTRUCTION MANUAL

©B64-1801-20 (MW)

Troubleshooting Guide

Specifications

Specifications subject to change without notice.

Laser diode ..................................................................................................GaAlAs (

λ=780 nm)

Digital Filter ..............................................................................................8 Time Over Sampling
D/A Converter.......................................................................................................................1 bit
Spindle speed.............................................................................................500 ~ 200 rpm (CLV)
Wow & Flutter......................................................................................Below Measurable Limit
Frequency Response (±1 dB) ...............................................................................5 Hz ~ 20 kHz
Total harmonic distortion (1 kHz) ...................................................................................0.005 %
Signal to Noise Ratio........................................................................................................100 dB
Dynamic range ...................................................................................................................94 dB
Channel separation.............................................................................................................96 dB
Operating voltage ...........................................................................14.4 V (11 ~ 16 V allowable)
Current consumption ................................................................................0.8 A at Rated power
Dimensions (W

× H × D)

(KDC-C717)........................................250

Ч 80 Ч 176 mm (9-13/16 Ч 3-1/8 Ч 6-13/16 in.)

(KDC-C667)........................................250

Ч 64 Ч 176 mm (9-13/16 Ч 2-1/2 Ч 6-13/16 in.)

Weight (KDC-C717) ............................................................................................2.0 kg (4.4 LBs)

Weight

(KDC-C667) ............................................................................................1.8 kg (4.0 LBs)

When removing the CD changer, be sure to first eject a magazine then unplug the changer cord. Do
not forget to attach the transport screws before transporting the CD changer.
The CD changer may be damaged during transport if a magazine or CD is left inside it or the transport
screws are not attached.

PROBLEM

POSSIBLE CAUSE

SOLUTION

Sound skips due to vibra-
tion.

The disc changer mode
cannot be selected.

• The unit is mounted at a slant.
• Changer unit is mounted in an

unstable place.

• The angle adjustment switches

are set improperly.

The O-N selection switch of the
disc changer is not set properly.

• Mount the unit so that is level.
• Mount the unit in a stable place.

• Set the angle adjustment

switches to the correct posi-
tions.

Set the O-N selection switch to
"O" position.
