PARTS LIST
# DESCRIPTION QTY
1 inner base 2
2 middle base 2
3 right rear upright 1
4 left rear upright 1
5 slide guide tube 2
6 left slide frame 1
7 right slide frame 1
8 top frame 2
9 guide rod 4
10 handle 2
11 top cross tube 1
12 weight shroud 4
13 double pulley block 2
14 swivel pulley block 2
15 cable 2
16 chin-up handle 1
17 selector rod 2
18 jam nut 2
19 pop pin 2
20 4.5" pulley 6
21 3.5" pulley 10
22 lat strap 2
23 ankle strap 2
24 end cap 8
25 plastic sleeve 4
26 plug 4
27 mushroom plug 4
28 grip 2
29 grip 2
30 long grip 2
31 pear hook 2
32 top plate 2
33 weight plate 10LBS 18
34 weight plate 5LBS 20
35 weight pin 2
36 small bushing 4
37 pulley spacer 8
38 weight bumper 4
39 bolt M12*20 4
40 bolt M10*70 8
41 bolt M10*65 8
42 bolt M10*75 4
43 bolt M10*50 10
44 bolt M10*35 2
45 bolt M10*55 2
46 bolt M10*25 4
47 bolt M10*140 2
48 bolt M10*135 2
49 allen bolt M8*10 12
50 chamber bolt M12*35 2
51 washer 12 4
52 washer 8 12
53 washer 10 76
54 nylon locknut M10 38
55 allen wrench S=6 1
