background image

PARTS LIST

#

DESCRIPTION

QTY

1

main frame

1

2

rear base

1

3

front frame

1

4

side angle frame

1

5

leg frame

1

6

circular plate w/shaft

1

7

weight holder

1

8

swing tube

1

9

back pad adjustable frame

1

10

adjustable roller pad frame

1

11

left handle

1

12

right handle

1

13

adjustable seat bracket

1

14

shalft with screw end

1

15

seat pad

1

16

back pad

1

17

stopper prone

1

18

washer 12

22

19

bolt M12X80

10

20

nylon lock nut M12

12

21

plate

2

22

long pop pin

1

23

bronze bushing ID25.4

4

24

split tension pin

1

25

plastic washer 46*26*3

1

26

washer 32*10.5*4

1

27

washer 10

7

28

bolt M10X25

7

29

spring clip

1

30

grease fitting

1

31

pop pin

2

32

L pin

1

33

big plug 25

2

34

allen bolt M8X6

2

35

plastic sleeve 50.8*44.5

4

36

plug 44.5

6

37

collar

2

38

plug 50.8

1

39

big roller pad

1

40

end cap 50.8

4

41

plastic tube

1

42

grip 2

43

foam pad 22*110*180

2

44

rubber sleeve

1

45

spring clip sleeve

2

^
