KF-SPC Parts list Rev A
Ref # Part # description Qty
1 3-0100 WEIGHT SUPPORT, KF-SPC 1
19-00591 SUPPORT, TELESCOPING ARM KF-SPC 1
3 3-01003 SEAT FRAME, KF-SPC 1
4 3-01044 REAR BASE, KF-SPC 1
5 10-0057 POP PIN (LOCKING), KF-45/KF-AAB 1
6 06-00187 BUMPER
7 8-0031 SEAT PAD, KF-SPC 1
8 8-003 PAD, ARM CURL KF-SPC 1
9 06-0039 FOOT CAP, RIGHT 50.8 KF SERIES
10 06-00393 FOOT CAP, LEFT 50.8 KF SERIES
11 06-0009 PLASTIC SLEEVE 50.8*76.
1 10-000 KNOB BOLT M1*5 1
13 0-00093 WASHER, 10 10
14 0-00615 BOLT, HEX HEAD M10X30, RESOLUTION
15 0-00636 SCREW, M8X5 BUTTON HEAD SOCKET CAP 4
16 0-00690 SCREW, BUTTON HD SOCKET CAP M10X90 1
17 0-00634 SCREW, M10X80 BUTTON HEAD SOCKET CAP
18 0-00694 SCREW, BUTTON HD SOCKET CAP M10X100
19 0-00091 NYLON NUT, M10 3
0 0-00094 WASHER 8, 9*8* 4
1 06-00391 SQUARE PLUG, 50.8 KF SERIES
7
Parts list
