PARTS LIST
# Description Qty
1 Weight Support 1
2 Telescoping Arm Support 1
3 Seat Frame 1
4 Rear Base 1
5 POP Pin 1
6 Bumper 2
7 Seat Pad 1
8 Arm Curl Pad 1
9 Wheel 2
10 Endcap 50.8 2
11 Plastic Sleeve 50.8x76.2x44.5x70 1
12 Knob M12*25 1
13 Washer 10 14
14 Bolt M10*30 2
15 Bolt M10*45 2
16 Bolt M10*90 1
17 Bolt M10*70 2
18 Bolt M10*100 2
19 Nylon Nut M10 5
EXPLODED VIEW
