PARKING LIGHT BULB:
Pull the bulb socket [2] out of the reflector and pull the bulb out of the bulb socket.
HEADLIGHT BULB:
Unplug the connector [3] and remove the rubber cap [4]. Turn the bulb socket [5] approx.
30° in a counterclockwise direction and remove.
Insert a new bulb, making sure the tabs [A] on the lamp engage in the recess [B] in the
headlight. Mount the bulb socket, rubber cap and connector.
Attach the headlight mask at the bottom, mount the screw and tighten to 10 Nm.
MAINTENANCE WORK ON CHASSIS AND ENGINE
»
54
Replacing the headlight lamp
Remove the screws [1], tilt the headlight mask up towards the front and detach at the
bottom.
Never touch the glass of the bulb with your fingers. The glass of the bulb must remain absolutely
free from grease. Heat will otherwise cause the grease to evaporate and settle down on the
reflector.
1 1
2
3
4
5
A
B
