FUNCTIONAL DESCRIPTION
CONTROLS AND COMPONENTS:
1. Battery Pack
2. Release Buttons on Each Side
3. 120V AC Adapter
4. Charger
5. LED Charging Indicators
6. 10mm (3/8") Keyless Chuck
7. 25 Adjustable Torque Settings
Control Ring
COMPONENT
MODEL NUMBER
BATTERY PACK
690506
120V AC ADAPTER
690074
CHARGER
690072
10mm (3/8") KEYLESS CHUCK 690076
8
7
Disconnect the plug or remove the battery pack from tool and place the switch
in the locked or “OFF” position before making any assembly adjustments,
changing accessories, performing any inspection, maintenance or cleaning
procedures. Such preventive safety measures reduce the risk of starting the
tool accidentally.
Do not use the Cordless Drill if it has been damaged, left outdoors in the
rain, snow, wet or damp environments, or immersed in liquid.
Maintain labels and nameplates on the Cordless Drill. These carry important
information. If unreadable or missing, contact Alltrade for a replacement.
SYMBOLS
IMPORTANT: Some of the following symbols may be used on your tool. Please
study them and learn their meaning. Proper interpretation of these symbols will
allow you to operate the tool better and safer.
SYMBOL
NAME
EXPLANATION
V
Volts
Voltage (Potential)
A
Amperes
Current
Hz
Hertz
Frequency (Cycles per Second)
W
Watt
Power
Kg
Kilograms
Weight
Alternating Current
Type of Current
Direct Current
Type of Current
Alternating or Direct Current
Type of Current
Earthing Terminal
Grounding Terminal
Class II Construction
Denotes Double Insulation
min
Minutes
Time
s
Seconds
Time
Diameter
Size of Drill Bits,
Grinding Wheels, etc.
No load speed
No-load Rotational Speed
.../min
Revolutions per Minute
Revolutions, Surface Speed,
Strokes, etc. per Minute
1,2,3, …
Ring Selector Settings
Speed, Torque or Position Settings
11
10
6
7
9
8
2
1
12
3
4
5
8. Forward/Reversing and
Trigger Lock Lever
9. Variable Speed Controlled
Trigger Switch
10. Accessory/Bit Holder
11. Comfort Rubber Grip
ACCESSORIES:
12. Double Ended Screwdriver Bits (2)
