KITCHENAID Side-by-Side Referigerator - Manual (Page 11)

11
Ingredient Care Center
The control for the ingredient care center adjusts the storage
temperature of the pan. Cold air flows into the pan through the air
duct between the freezer and the refrigerator. Setting the controls
allows more or less cold air through the air duct.
To adjust the ingredient care center:
1. Choose a setting based on the item to be stored in the pan.
2. Push the button that corresponds to that setting.
3. The indicator light for that setting will illuminate to verify that
the pan is ready to be loaded.
To remove and replace the ingredient care center cover:
1. Remove food from ingredient care center cover. Pull drawer
out about 4 in. (10.16 cm). Reach under the glass shelf with
both hands and lift gently upward until back of shelf is free.
Tilt shelf at an angle and remove shelf from refrigerator being
careful not to bump the glass.
2. Replace the cover by holding the glass shelf firmly with both
hands, tilt the shelf at an angle and position it above the
support rails. Place shelf gently on support rails on side wall.
Meat Storage Guide
Store most meat in original wrapping as long as it is airtight and
moisture-proof. Rewrap if necessary. See the following chart for
storage times. When storing meat longer than the times given,
freeze the meat.
Fresh fish or shellfish ................. use same day as purchased
Chicken, ground beef, variety meat (liver, etc.)......... 1-2 days
Cold cuts, steaks/roasts ........................................... 3-5 days
Cured meats ........................................................... 7-10 days
Leftovers - Cover leftovers with plastic wrap, aluminum foil, or
plastic containers with tight lids.
Crisper and Covers
To remove and replace the crispers:
1. Remove contents from the crisper.
2. Slide the crisper drawer straight out to the stop. Lift the front
of the drawer with one hand while supporting the bottom of
the drawer with your other hand and slide the drawer out the
rest of the way.
3. To replace the crisper drawer, place the drawer onto slides
and push the drawer back until securely in position.
4. Carefully test the crisper drawer to make sure it has been
replaced properly.
To clean the crisper covers:
1. To clean the top crisper cover, remove the ingredient care
center located above it.
2. To clean the bottom crisper cover, first remove the top crisper
drawer.
Covered Utility Bin
NOTE: For long-term storage, store eggs in a covered container
or in their original carton on an interior shelf.
Wine Rack
To remove and replace the wine rack:
1. Remove the rack by pulling it straight out from the shelf.
2. Replace the rack by sliding it in between the shelf and the
wall of the refrigerator.
FREEZER FEATURES
Ice Maker and Storage Bin/Bucket
(on some models - Accessory)
Style 1
To turn the ice maker on/off:
The on/off switch for the ice maker is a wire shutoff arm located
on the side of the ice maker.
1. To turn the ice maker on, simply lower the wire shutoff arm.
NOTE: Your ice maker has an automatic shutoff. As ice is
made, the ice cubes will fill the ice storage bin and the ice
cubes will raise the wire shutoff arm to the OFF (arm up)
position.
