VIII.-LIST EXTERNAL PARTS UPRIGHT VACUUM CLEANER U-80 AND U-90
9 DECEMBER-10
EXTERNAL PARST OF PLASTIC UPRIGHT
No PART No DESCRIPTION U-90
1 13-0947-5 HANDLE GRIP 1
2 05-4091-01-2 UPPER HANDLE BACK 1
3 01-0290-5 SCREW 10 X 3/8 2
4 05-4089-01-6 CORD HOOK BLACK U-75 1
5 13-1462-4 CORD RETAINER 1
6 01-0283-0 SCREW 8 X ½ 1
7 02-0141-8 LOCK NYLON NUT 2
8 05-4090-01-4 LOWER HANDLE BLACK U-75 1
9 17-4777-01-1 LABEL U-75/95 1
10 13-3825-01-8 TAMPO-PLASTIC CHASSIS 1
11 13-2949-03-3 TAMPO- PLASTIC COVER 1
12 13-0304-9 RETEN CABLE 1
13 12-0814-01-7 BELT .0250 X 3 7/16” 1
14 01-2034-01-3 SPECIAL SCREW FOR HANDLE 1
15 01-2034-5 SPECIAL SCREW FOR HANDLE 10-32 X 1 ¾ 1
EXTERNAL PARST OF PLASTIC UPRIGHT
No PART No DESCRIPTION U-80
1 13-0947-5 HANDLE GRIP 1
2 05-4091-01-2 UPPER HANDLE BACK 1
3 01-0290-5 SCREW 10 X 3/8 2
4 05-4089-01-6 CORD HOOK BLACK U-75 1
5 13-1462-4 CORD RETAINER 1
6 01-0283-0 SCREW 8 X ½ 1
7 02-0141-8 LOCK NYLON NUT 2
8 05-4090-01-4 LOWER HANDLE BLACK U-75 1
9 17-4777-01-1 LABEL U-75/95 1
10 13-2883-0 PLASTIC CHASSIS 1
11 13-2949-03-3 TAMPO- PLASTIC COVER 1
12 13-0304-9 RETEN CABLE 1
13 12-0814-01-7 BELT .0250 X 3 7/16” 1
14 01-2034-01-3 SPECIAL SCREW FOR HANDLE 1
15 01-2034-5 SPECIAL SCREW FOR HANDLE 10-32 X 1 ¾ 1
