Keys Fitness AbdominAl CrunCh KF-AC - Manual (Page 10)

10
KF-AC Parts list Rev A
Ref # Part # description Qty
1 223-00976 FRONT BASE, KF-AC 1
2 223-00977 BACK BASE, KF-AC 1
3 223-00978 FRAME, PAD SUPPORT KF-AC 1
4 219-00465 ROLLER PAD TUBE, KPS-AC 2
5 228-00224 PAD, KF-AC 1
6 206-00392 FOOT CAP, RIGHT 50.8 KF SERIES 4
7 206-00390 PLUG, ROLLER PAD TUBE CAP, KF SERIES 4
8 206-00395 FOAM PADDING, 100X22X180 KF SERIES 4
9 202-00634 SCREW, M10X80 BUTTON HEAD SOCKET CAP 2
10 202-00223 WASHER, 11X23X2 6
11 202-00091 NYLON NUT, M10 2
12 202-00115 WASHER M8 8
13 202-00636 SCREW, M8X25 BUTTON HEAD SOCKET CAP 8
14 202-00690 SCREW, BUTTON HD SOCKET CAP M10X90 2
15 206-00391 SQUARE PLUG, 50.8 KF SERIES 4
16 206-00393 FOOT CAP, LEFT 50.8 KF SERIES 4
# 202-00691 BOLT PACK, KF-AC 1
Parts list
