Kyocera KM-3650w - Manual (Page 8)

Chapter 1 Before Use 1-5
1. 3. 2 Printer part
Subject Specification
Printing method
LED Array Electro photography
Photoreceptor Organic Photoconductive Drum
Print speed 60mm per second
(Metric) -
(Inch) 2.6ppm/E 4.4ppm/D Landscape
Print head LED Array
Resolution of print head 600dpi x 600dpi
Print width Maximum 914mm (36 inches)
Minimum 297mm or 11” (Roll paper)
210mm (Cut sheet paper)
Print length Maximum
Plain paper 3600mm (36” paper)
Or “3 x each standard length” (34” or narrower)
Tracing 2 x each standard length
Film 1 x each standard length
Minimum 210mm
Warm up time Shorter than 5 minutes
(At 23
o C, 60%RH, the rated voltage, and plain paper is used)
First print time 24 seconds (D Landscape / 100% / Roll1)
Fusing method Heat and Pressure Rollers
Development method Dry type non-magnetic mono-component toner
Media (Recommended Media)
Plain Paper 64 to 80g/m 2 US Bond (PB-20)
Tracing Paper US Vellum (XV-20)
Film 4MIL (PF4DME)
Storage of consumables (Toner cartridge)
Store the cartridge within the temperature range from 0 to
35 degrees Centigrade and within the humidity range from 10
to 85% RH.
NOTE
A longer print than the above lengths is available optionally.
(24 meters max.)
But note that we will not guarantee the image quality or
reliability of paper feeding if the print is longer than the above
lengths.
NOTE
The above specifications may change without notice.
