16
PARTS LIST
MODEL NO.: CX1830GS-8
CX1836GS-8
CX1842GS-8
NO. DESCRIPTION MODEL /SIZE PART NO.
1 Oil Container (Round) 1-HAN-M001
2 Stainless Steel Filter Screw FT-S-1
3 Stainless Steel Filter 1-FBL-A009
4 Stainless Steel Mesh Filter 1-HGF-A100
5 Halogen Light Support 1-FAV-J703
6 Halogen Light (12V 20W Max.) 1-FAV-ZJ01
7 Bottom Casing 1-FAZ-A001
8 Control Board ,
Control Button
1-HDC-G100,
1-FAZ-J100
9 Control Box Screw FT-S-2
10 Hood Casing 1-FAZ-A100
11 Hood-Mounting Bracket 1-FAZ-M002
12 Plastic Damper 1-FAV-M011
13 Transformer 1-HAN-J101
14 Electrical Wire Box 1-FAV-G001
15 Processor Board 1-FAX-G100
16 Capacitor 1-HAN-G001
17 Rubber Seal 1-FAV-M005
18 Air Chamber 1-FAV-F160
19 Motor 1-HAN-F110
20 Blower 1-FAV-F170
21 Locknut 1-FAA-F205
22 Blower Cover 1-FAV-F120
23 Duct Cover-Mounting Bracket 1-FAV-M020
24 Inner Duct Cover 1-HJS-M001
25 Air Chamber Cover 1-FAV-A006
26 Outer Duct Cover 1-HJS-A100
2 7 Glass Canopy Screw FT-S-4
30” CX183-30G
36” CX183-36G
2 8 Glass Canopy
42” CX183-42G
29 LED Screen 1-FAZ-A002
30 Control Panel Screw FT-S-3
RECIRCULATING KIT (Optional) Model No.: RD-0183
NO.
DESCRIPTION MODEL/SIZE PART NO.
31 T-Box 1-HGF-M100
32 Carbon Filter Frame 1-HGF-A100
33 Carbon Filter 1-HJT-F101
