KF-45 Parts List Rev B
Ref # Part # description Qty
1 223-00872 U BASE FRAME, KF-45 1
2 223-00873 T BASE FRAME, KF-45 1
3 223-00874 MAIN FRAME, KF-45 1
4 223-00875 ADJUSTMENT FRAME, KF-45 1
5 210-00022 KNOB BOLT M12*25 1
6 210-00257 POP PIN (LOCKING), KF-45/KF-AAB 1
7 219-00537 FOAM TUBE, KF SERIES 1
8 206-00392 FOOT CAP, RIGHT 50.8 KF SERIES 2
9 206-00395 FOAM PADDING, 100X22X180 KF SERIES 2
10 206-00391 SQUARE PLUG, 50.8 KF SERIES 3
11 206-00390 PLUG, ROLLER PAD TUBE CAP, KF SERIES 2
12 206-00388 EZ GLIDE SLEEVE KF-45 2
13 228-00198 CHEST PAD, LEFT KF-45 (#13) 1
14 206-00389 HAND GRIP, KF-45/KF-AAB 2
15 206-00138 ROUND PLUG 25 2
16 206-00118 ENDCAP W/WHEEL 60 2
17 206-00394 PLUG, 50.8X76.2 KF SERIES 2
18 202-00215 NON SLIP PAPER 2
19 202-00634 SCREW, M10X80 BUTTON HEAD SOCKET CAP 4
20 202-00635 SCREW, M10X30 BUTTON HEAD SOCKET CAP 4
21 202-00636 SCREW, M8X25 BUTTON HEAD SOCKET CAP 4
22 202-00091 NYLON NUT, M10 4
23 202-00093 WASHER, 10 12
24 202-00094 WASHER 8, 9*28*2 4
27 206-00393 FOOT CAP, LEFT 50.8 KF SERIES 2
28 228-00199 CHEST PAD, RIGHT KF-45 (#28) 1
# 215-00093 MANUAL KF-45 1
Parts List
