KITCHENAID KUIS185GBT0 - Manual (Page 2)

CABINET LINER AND DOOR PARTS
2
For Models: KUIS185GBT0
(BISCUIT)
4398115
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 2181180 Shell
2 2175619 Front, Shell
3 756330 Door, Inner Bin
4 758655 Liner, Door
5 593192 Plug, Hinge
6 593104 Strip, Tapping (2)
7 2181190 Trim, Door (2)
8 593184 Rail, R.S.
593185 Rail, L.S.
9 681459 Screw,
8-32 x 5/8 (6)
10 758492 Washer (2)
11 759213 Tube, Water Fill
12 2180752 Liner (Includes
Nos. 10, 11, 17,
19, 21, and 35)
13 2172898 Gasket, Bottom
14 596023 Clamp (2)
15 758921 Gasket
16 487909 Screw #8 x 1/2
17 596807 Grommet
18 756891 Insulation,
Bottom, Foam
19 681542 Nut
20 2181187 Handle, Door
21 758220 Stud (2)
22 593183 Well, Bin
Thermostat
23 596812 Clip, Panel (12)
24 2181189 Pocket, Handle
25 2181188 Panel, Exterior
26 2181194 Panel, Outer
28 593577 Connector, Hose
29 585158 Scoop
30 680811 Screw, 10-32 x 3/8
32 2181157 Harness, Cabinet
34 680930 Thumbscrew,
10-1/2
35 596715 Well Nut (3)
36 2181196 Trim, Side (2)
37 758608 Insulation, Door
38 681196 Screw
39 681419 Thumbscrew
42 681613 Washer
44 2181195 Trim, Top
And Bottom
47 2181193 Grill, Front
49 758771 Panel, Inner
51 2181191 Trim, Door
(Lower)
52 2175604 Support, Front
53 489482 Retainer, Wire
FOLLOWING PARTS
NOT ILLUSTRATED
OPTIONAL PARTS NOT INCLUDED
503695 Sealer, Cork
(1/4 Pound)
797403 Cement, Insulation
(1 Oz.)
505587 Sealer, Mastic
(1 Qt.)
212643 Sealer, Gum
(22 Pcs. 3/16" x 7")
479976 Kit, Insulation
(5 Pcs. 3" x 24"
x 48")
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
LITERATURE PARTS
LIT2181092 Use & Care Guide
LIT2175675 Instructions,
Installation
LIT2180830 Service and Wiring
Sheet
