5

Assembly

Insert the Leg Developer Holder (01) into the front opening of Main Frame and secured with a
knob bolt.

Attach the Leg Developer (02) to the bracket of the Leg Holder (01), and assemble use one Hex
Bolt M10X75 (03), two Washers D10 (04) and one Aircraft nut (05).

Insert one Foam Tube (06) halfway through the hole on the Leg Developer Holder (01). Insert
two Foam Tubes (06) halfway through the holes on the Leg Developer (02). Push six Foams (07)
onto the Tubes from both sides.

Slide the Olympic Sleeve (08) onto the weight holder in front of the Leg Developer (02). Attach a
Spring Clip (09).

Note: See Exploded View on Pg 6 for Image.

NOTE: Hand Tighten bolts and nylon nuts until machine is fully assembled

.
