• Press the On/Off switch
¸ to
activate the laser.
• Adjust the Measuring Tape with
Marking Laser, with the assistance
of the foot screws
ᕧ, such that
the bubbles in the spirit levels
ᕥ
and
ᕦ lie exactly between the
markings. If you screw out the
foot screw
ᕧ a little further, you
can project the laser line somewhat
higher.
• Direct the laser line onto the
desired wall.
• Turn the covering flap
ᕩ all the
way to the left or right, dependant
on whether you wish to project
a vertical or a horizontal line.
