GRILL PARTS
2
For Model: KFRU488VSS00
(Stainless Steel)
W10270307
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10175731 Use & Care Guide
2 W10244182 Cover, Rear(2)
3 W10244183 Panel, Rear
4 W10244332 Panel, Access
5 W10247108 Bracket, Panel
Left
6 W10247107 Bracket, Panel
Right
7 W10247109 Bracket, Warming
Rack
8 W10128637 Cover, Access
Panel
9 W10244338 Clip, Wire
10 Not Serviced
11 W10247110 Hole Plug
12 W10244959 Panel, Side Left
13 W10244962 Bracket, Grease
Tray (Right)
14 W10128655 Roller, Drip Tray
15 W10244966 Drip Tray Assy
(Includes Rollers)
16 W10244965 Bracket, Grease
Tray (Left)
18 W10244195 Flex Tube,
Manifold
19 W10244963 Tray, Grease
21 W10140245 Harness, Wire
Light
24 W10285657 Nameplate
25 W10285660 Knob, Main Burner
26
W10134822 Knob, Rear Burner
27 W10128756 Bezel, Knob
28 W10244964 Tray, Grease
29 W10244947 Panel, Control
30 W10140236 Harness, Wire
Control
31 W10244954 Valve, Main Brnr
32 W10244951 Valve, Rear Brnr
33 W10244173 Spring, Hood
34 W10244957 Manifold
35 W10244958 Baffle, Front
36 W10140257 Washer, Flat
37 W10244341 Side Panel, Right
38 W10244340 Panel, Outer (RT)
39 W10128660 Handle, Shelf
40 W10128777 Thermometer
41 W10128779 Bezel, Thermometer
42 W10247023 Panel, Grease Tray
44 W10140208 Handle, Hood
45 W10128785 Endcap, Handle
(Left)
46 W10128786 Spacer, Handle
47 W10128787 Endcap, Handle
(Right)
48 W10128788 Hinge, Lid
49 W10244172 Hood
50 W10247115 Transformer,
Rotisserie Motor
51 W10247106 Bracket, Spit
52 W10128659 Bracket, Handle
53 W10136946 Shelf, Side (LF)
54 W10128662 Bar, Tool
56 W10246810 Regulator (NG)
57 W10246811 Kit, Orifice NG
58 W10246809 Connector (Brass)
59 W10304337 Harness, Power
60 W10304338 Harness, Power
61 W10247197 Fork, Spit
62 W10140240 Rod, Spit
63 W10167017 Motor, Rotisserie
64 W10247113 Bracket, Rot. Mtr.
65 W10244953 Valve, Sear Burner
66 W10244949 Valve, Side Burner
67 W10304339 Harness, Display
68 W10304340 Harness, Display
69 W10244955 Box, Display
70 W10244956 Box, UI Inner
71 W10244948 Wire, Display
72 W10244945 Display, UI
73 W10244946 Button, Display
74 W10247196 Regulator, LP
75 W10244337 Valve, Flange
76
W10244333 Connector, Brass
77 W10247149 Valve, Safety
78 W10244336 Box, Insulator
79 W10140243 Bracket, Middle
80 W10244967 Tray, Grease
