21
SPECIFICATIONS
MODEL / SIZE CH7930SQB / 30”
CH7936SQB / 36"
CH7942SQB / 42"
CH7948SQB / 48"
COLOR
Commercial Grade Stainless Steel
CONSUMPTION / AMPERE
30” – 232W / 2.21A
36” – 232W / 2.21A
42” – 253W / 2.38A
48” – 258W / 2.41A
NUMBER OF MOTORS 2
DESIGN 18-Gauge Seamless / Satin Finish
FAN TYPE Twin Turbine Impeller
EXHAUST Top –
6" Round
7" Round
3-1/4" x 10" Rectangular
Rear –
3-1/4" x 10" Rectangular
CONTROLS Electronic Control (4 Buttons) –
10-Second Standby Startup
30-Second Delay Shutoff
HALOGEN LIGHTS
Or LED (if Available) 30” - 12V 20W x 2
36” - 12V 20W x 2
42” - 12V 20W x 3
48” - 12V 20W x 3
HOOD DIMENSION
(W x D x H) (CH7930SQB) 29-3/4” x 22” x 9-1/8”
(CH7936SQB) 35-3/4” x 22” x 9-1/8”
(CH7942SQB) 41-3/4” x 22” x 9-1/8”
(CH7948SQB) 47-3/4” x 22” x 9-1/8”
OPTIONAL ACCESSORIES
(W x D x H) 1) 30" Stainless Steel Back Panel (SSP30) 30" x 1/10" x 32"
2) 36" Stainless Steel Back Panel (SSP36) 36" x 1/10" x 32"
3) Two-Piece Adjustable Duct Cover
(CH1120DC) 11-7/8” x 10-1/4” x (20-5/8” ~ 39-3/4”)
WEIGHT (lbs) Net Gross
(CH7930SQB) 45 64
(CH7936SQB) 47 66
(CH7942SQB) 50 70
(CH7948SQB) 53 75
SPEED QuietMode
 Low Medium High
Air Capacity (cfm)* 280 430 580 720
Sone 1.0 2.8 4.2 4.5
* In House Test Static Pressure “0”. One sone is equivalent to the sound of a refrigerator at 40 decibels.
**Specifications subject to change without notice.
