Keys Fitness Strength trainer ST-1000 - Manual (Page 8)

PARTS LIST
]
# DESCRIPTION QTY
1 Base Frame 1
2 Foot Plate 1
3 Main Upright 1
4 Rear Cross Beam 1
5 Rear Top Beam 1
6 Main Top Beam 1
7 Foot Plate Bracket 1
8 Lat Pull Down Bar 1
9 Seat Pad Support Receptacle 1
10 Leg Extension Lever 1
11 Back Pad Support 1
12 Press Arm Support 1
13 Press Arm 1
15 Rear Upright 1
16 Front Cross Link Beam 1
17 L-Pin (Long) 1
18 Seat Pad Support 1
19 Leg Press Main Frame 1
20 Bushing (Long) 6
21 Foam Tubing 1
22 Foam Tubing 1
23 Knee Hold Down Bar 1
24 Guide Rod 2
25 Weight Stack Cover 1
26 Weight Stack Cover 1
27 Seat Pad (Main Frame) 1
28 Back Pad (Main Frame) 1
29 Back Pad (Leg Press) 1
30 Seat Pad (Leg Press) 1
31 Foot Plate Support Connector 1
32 Foot Plate Support 1
33 Foot Plate 1
34 Back Pad Support 1
35 Handle (Left) 1
36 Handle (Right) 1
37 U Beam 1
38 Shaft 2
39 Shaft 2
41 Limiter 4
42 C Clamp 2
43 Shaft 2
44 Bolt 2
45 Sleeve 4
# DESCRIPTION QTY
46 Bushing 20
47 Double Pulley Bracket 4
48 Lat Pull Bar 1
49 Low Pull Bar 1
50 Weight Plate Assembly 1
51 Selector Rod 1
52 Selector Pin 1
53 Chain 1
54 Chain 1
55 Hook 5
56 Nylon Handle 1
57 Ab Strap 1
58 Foam Roller 6
59 Foam Grip 2
61 Pulley 23
62 Cable 1
63 Cable 1
64 Cable 1
65 Rubber Cushion 2
66 Mark Sticker 1
67 Mark Sticker 1
68 Pull Pin (Long) 1
69 Pull Pin 1
70 L-Pin 1
71 Nylon Stopper 1
72 Bronze Bushing 4
73 Bushing 2
74 Bushing 4
75 Bushing 4
76 Spring Washer 4
77 Spring Washer 4
78 Pull Pin 2
79 Rubber Cushion 1
80 Handle Grip 4
81 End Cap 100*50 4
82 End Cap 50 8
83 End Cap 45 1
84 End Cap 60*30 2
85 End Cap 50*25 7
86 End Cap 50.8 4
87 End Cap 25 8
88 Bolt M10*125 3
89 Bolt M10*120 1
# DESCRIPTION QTY
90 Bolt M10*115 1
91 Bolt M10*95 2
92 Bolt M10*85 3
93 Bolt M10*80 1
94 Bolt M10*75 16
95 Bolt M10*70 12
96 Bolt M10*65 2
97 Bolt M10*50 2
98 Bolt M10*45 6
99 Bolt M10*35 2
100 Bolt M10*25 2
101 Bolt M8*65 2
102 Bolt M8*50 2
103 Bolt M*15 1
104 Bolt M8*120 1
105 Bolt M12*85 1
106 Phillip Screw M12*35 1
107 Hex Screw M8*15 8
108 Hex Screw M8*10 8
109 Hex Screw M*15 4
110 Phillip Screw M6*20 1
111 Washer 13*24*1.5 10
112 Washer 11*20*2 101
113 Washer 9*16*1.6 11
114 Washer 22*9*2 8
115 Nut M12 7
116 Nut M10 48
117 Nut M8 5
118 Guide Rod Support 1
119 Hex Screw 2
120 Allen Wrench 1
123 Allen Bolt M10x50 2
125 Rubber Weight Bumper 2
126 Square 50*25 Plug 5
127 Bolt M12x75 2
128 Ankle Strap 1
129 Grip Foam 70x38x135 4
130 Weight Plate 19
