3
KENTROX CARE SERVICE AND SUPPORT PART #
Onsite 7x24x4 13803
Onsite 5x8x4 13813
Onsite 7x24xNBD 13802
Onsite 5x8xNBD 13812
Basic 7x24xNBD 13804
Exchange NBD 13809
Onsite Installation 13820
Phone Installation 13830
KENTROX TECHNICAL TRAINING PART #
Customer Site
Basic Confi g & Maintenance Lecture, 1 day
133811
Advanced Confi g & Maintenance Lecture, 1 day 133812
Per student charge for lecture in excess of
8 students, per day
133819
Kentrox Campus
Basic Confi g & Maintenance Lecture, 1 day
133851
Advanced Confi g & Maintenance Lecture, 1 day 133852
ORDERING INFORMATION
DESCRIPTION CATALOG #
Q2300 Ethernet QoS Access Router 2300
Q2301 Ethernet QoS Access Router with Modem 2301
Items included with the Q2300 and Q2301:
- Documentation CD (includes Adobe® Acrobat® PDF versions of
the Setup Guide, the User’s Guide and the CLI Reference Guide)
- AC-DC power adapter and cable for use in North America
- One 6’ Ethernet LAN cable, Cat 5E, UTP 568B
- One CLI serial to PC adapter, RJ45 female to DE9 female
(for use with external Ethernet cable)
- Two #8 wood screws and anchors for wall-mounting
Ethernet Cable, Cat 5E, 6' 93006212
Q2300 19" Rack Mounting Kit 77912
Q2300 CLI Serial to PC Adapter, RJ45 Female to DE9
Female (for use with external Ethernet cable) 77910
Protect your network investment with
support plans and technical training
To keep your network healthy and productive, Kentrox
offers Kentrox Care Support Plans for our Q-Series™
access routers. Kentrox technical training courses are also
available on site or at the Kentrox campus to help you get
the most out of your Q-Series routers. For details, visit our
website at
www.kentrox.com/services.
Figure 4: The Kentrox Q2300 router offers an intuitive, Web-style GUI to simplify setup and management.
10/100
WAN
Modem
(optional)
Control
port
4 x 10/100
LAN
10/100M ETHERNET LAN Ethernet WAN MODEM RS-232 LINK LINK LINK LINK 10BT 10BT 10BT 10BT ACT ACT ALM ALM
PORT 1 PORT 2 PORT 3 PORT 4
RESET
POWER
12 VDC
