11
REPAIR PARTS LIST
KEY
NO
PART NUMBER DESCRIPTION
NO.
Model No.
625.343920
Model No.
625.343950
1 7160453 7160453 Screw, #10 – 14 x 3/4” (8 req.)
2 7182502 7182502 Mounting Bracket (includes screws)
3 9006053 9006053 Screw, #10 – 14 x 1–1/4” (2 req.)
4 9003203 9003203 Nut, 3/8” Tube (2 req.)
5 7131349 7131349 Tubing Insert, 3/8” (2 req.)
6 9004503 9004503 Elbow, 3/8” NPT x 3/8” Tube (2 req.)
7 7156535 7156535 Head
8 7161255 7161255 Nipple, 3/8” NPT x 1 – 1/2”
9 42–34385 42–34385 O–ring, 3–3/8” I.D. x 3–5/8” O.D. (2 req.)
10 7156577 7156569 Sump (2 req.)
11 7160437 7160437 Head Assembly – includes vent assembly
12 7164936 7164936 Vent Assembly
13 7174961 7174961 Tubing, 3/8” x 90”
14 9043201 9043201 Nut, 3/8”
15 7064144 7064144 Tubing Adaptor – incls. key nos. 14 & 16 (2 req.)
16 1260600 1260600 Washer
17 7011272 7011272 Supply Saddle Valve
18 7161263 7161263 Faucet Assembly
19 ––– 7161352 Electronic Base – incls. key nos. 20 through 23
20 ––– 0900156 Screw, #6 – 32 x 5/8”
21 ––– 0900713 Screw, #6 – 32 x 1 – 3/8” (2 req.)
22 ––– 7163469 Faucet Support – incl. cover for screw, key no. 20
23 ––– 7115725 Nut (2 req.)
24 ––– 7162552 Battery Pack – does not include batteries ➀
z 7182586 7182586 Owners Manual
v 42–34360 42–34360 Sediment Cartridge, 25 micron
v
42–34362 42–34362 Sediment Cartridge, 5 micron
v
42–34370 42–34370 Taste & Odor Cartridge, 95% chlorine reduction
v
42–34372 42–34372 Taste & Odor Cartridge, 99% chlorine reduction
v 42–34365 42–34365 Taste & Odor / Chemical Contaminate Cartridge
v
42–34377 42–34377 Taste & Odor / Lead Cartridge
v
42–34330 42–34330 Sump Cleaning Kit
v 42–34331 42–34331 Sump Cleaning Solution
v
42–34334 42–34334 Sump Removal Wrench
z not illustrated
v available options from Sears at time of this printing, not illustrated, and not included
with Water Filter System
➀ requires 2, AA alkaline batteries
