Tc-48-xb-tiller: parts list – King Kutter 999995 User Manual
Page 29
29
Ref.
Part Name
Part Number
TC-48-XB
1
Lift Arm Brace
904010
2
3
6
7
9
10
11
12
13
14
15
Lift Arm (left hand)
Lift Arm (right hand)
Lift Arm Spacer Kit
Tine Pkg. (3 right & 3 left) w/bolts
Tine Bolt Pkg. (60 pcs.)
Skid Left
Skid Right
Chain & Shackle Kit
Top Gearbox Parts
Side Gearbox Parts
Lift Pins CAT.#1(2pk)
Rotor
8
4
Tail Rod Assembly
5
Cover Assembly Kit
Tine Bolt Pkg. (12 pcs.)
No.
904002
904005
504200
504201
504202
504205
504207
504208
904056
904051
504203
See Page 34
See Page 32
500001
904065
7
Tine Pkg. (1 right & 1 left) w/ bolts
504204
16
17
Back Plate
Support Stand Assembly
18
904070
504209
Oil Plug/Gage
904021
8
TC-48-XB-TILLER: PARTS LIST
7
4' Complete Tine Pkg. (30pcs.)
504206
19
Frame
904047
