Clutch lever
The clutch lever
[1] is located on the left side of the handlebar. The adjusting screw [A] is
used to change the original position of the clutch lever (see maintenance work on chassis
and engine).
The clutch is hydraulically actuated and adjusts itself automatically.
Hand brake lever
The hand brake lever
[2] is mounted on the handlebars on the right and actuates the front
wheel brake. The adjusting screw
[B] can be used to change the basic position of the hand
brake lever (see Maintenance).
OPERATION INSTRUMENTS
»
7
B
2
1
A
