Step 1
Connect Left and Right Support Frames (17,18) to main Base Frame (19) using:
x (57) Bolt 4 x (49) Washer x (1) Nylon Lock Nut
Attach Rear Base Frame (5) and Upright Frame (1) to Main Base Frame (19) using:
x (57) Bolt 4 x (49) Washer x (1) Nylon Lock Nut
Attach Left and Right Slide Frames (3,4) to Left and Right Support Frames (17,18) using:
4 x (5) Bolt 8 x (49) Washer 4 x (1) Nylon Lock Nut
Secure Top Cross Frame () to Left and Right Slide Frames (3,4) and Upright Frame (1) using:
x (59) Bolt x (49) Washer 4 x (1) Nylon Lock Nut
x (5) Bolt 4 x (7) Washer
4 x (53) Bolt 4 x (48) Washer
67
67
67
3
17
56
57
49
57
49
49
67
61
49
61
61
56
49
67
4
18
19
25 1
49 57
49
48
49
49
61
61
2
59
59 67
67
49
65
49
61
61
65
61
67
53
53 48
49
61
61
49
7
Assembly
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
