Karcher K 6.85 M - Manual (Page 10)

10
English
Australia
Kärcher Pty. Ltd.
40 Koornang Road
Scoresby, Victoria 3179
1800 675 714 (Free Call)
www.karcher.com.au
Subject to technical modifications!
Customer Service Technical specifications
Power connection
Voltage
230-240
1~50
V
Hz
Connected load 2,2 kW
Mains fuse (slow-blow) 16 A
Maximum allowed net im-
pedance 0,388
+ j0,243
Ohm
Ohm
Protective class I
Protection class IP X5
Water connection
Max. feed temperature
60 °C
Min. feed volume 11 I/min
Max. feed pressure 0,6 MPa
Max. Suction height 0,5 m
Performance data
Working pressure
13 MPa
Max. permissible pressure 15 MPa
Water flow rate 8,2 I/min
Detergent flow rate 0-0,2 I/min
Recoil force of trigger gun 21 N
Hand-arm vibration
(ISO 5349) 0,8 m/s 2
Sound pressure level
L
pA
(EN60704-1)
73 dB(A)
Sound power level
L
WA
(2000/14/EG)
92 dB(A)
Dimensions
Length
400 mm
Width 395 mm
Height 925 mm
Weight 19 kg
