Owner’s Reference
Krell Interface Dock
Papa Dock
POWER
POWER
BASS
TREBLE
VOLUME
AUX
INPUT
Specifications
12 Krell / Papa Dock
Inputs
1 30-pin iPod-device type
1 3-conductor 3.5 mm connector
Audio Outputs
1 pair balanced via XLR connectors
1 pair single-ended via RCA connectors
Video Outputs
1 S-Video via a DIN connector
1 Composite via a RCA connector
Control Inputs
1 RS-232 input via a 9-pin D-subminiature connector
Control Outputs
1 12 VDC trigger output via 2-conductor
3.5 mm connectors (500 milliamps maximum
per output)
Input impedance
Single-ended: 47.5 k Ohms
Output impedance
Balanced: 50 Ohms
Single-ended: 25 Ohms
Volume Control
256-step Digital Control
Input Overload
Single-ended:
4 Vrms
Output Overload
Balanced: 16 Vrms
Single-ended: 8 Vrms
Frequency Response
20 Hz to 20 kHz +0.7 dB, -0.0 dB
0.1 Hz to 90 kHz +0.7, -3 dB
Tone Control Range
Bass:
+8 dB, -7 dB
Treble: +6 dB, -6 dB
Total Harmonic Distortion Plus Noise
Balanced Output: <0.002%, 20 Hz to 20 kHz,
4 V RMS or 4 mA rms
Signal-to-noise Ratio
Wideband, Unweighted:
>94 dB
“A” Weighted: >97 dB
Power Consumption
Standby:
10 W
Power on: 25 W
Dimensions
Inches:
13 W x 2.8 H x 10.9 D
Centimeters: 33.0 W x 7.0 H x 27.7 D
Weight
Unit Only: 10 lb., 4.5 kg
Shipped: 14 lb., 6.4 kg
Your KID product serial number is:
KID SPECIFICATIONS
PAPA DOCK SPECIFICATIONS
All operational features, functions, specifications, and
policies are subject to change without notification.
P/N 301038 v 08.0
Frequency Response
20 Hz to 20 kHz, +0, -0.15 dB
<0.2 Hz to 110 kHz,+0 dB, -3 dB
Signal-to-noise Ratio
Wideband, unweighted, referred to full power output:
>108 dB
“A” weighted: >116 dB
Gain: 26.2 dB
Total Harmonic Distortion (THD)
< 0.03%@ 1 kHz, at 150 W, 8 Ohms
< 0.20%@ 20 kHz, at 150 W, 8 Ohms
Input Impedance
90 kOhms
Input Sensitivity
1.70 Vrms
Output Power, each channel driven:
150 Wrms @ 8 Ohms
300 Wrms @ 4 Ohms
Output voltage
98 V peak-to-peak, 35 Vrms
Output current: 15 A peak
Slew Rate: 50 V/
µs
Output Impedance
<0.073 Ohms at 20 Hz
<0.084 Ohms, 20 Hz to 20 kHz<
Dampening Factor
110 at 20 Hz, referred to 8 Ohms
95, 20 Hz to 20 kHz, referred to 8 Ohms
Power Consumption
Stand-by: 25 W, Idle: 55 W, Maximum: 900 W
Heat Output, BTU/hr.
Stand-by: 85, Idle: 190, Maximum: 1100
Inputs
1 40-pin KID connector
1 RS-232 (to control KID) via a 9-pin
D-subminiature connector
Outputs
2 channel via 5-way binding posts
Remote Connectors
One 12 VDC output (12 V trigger), 30 mA maxi-
mum, via a 3.5 mm connector
S-Video (from KID) via mini-DIN connector
1 composite video (from KID) via RCA connector
Dimensions
Inches: 17.3 W x 5.7 H x 16.3 D
Centimeters: 43.8 W x 14.5 H x 41.3 D
Weight
Unit Only:
39 lb., 17.6 kg
Shipped: 49 lb., 22.2 kg
