Controls, displays and connections
4
Front panel controls and displays Rear panel controls and connections
1 Mains switch (with mains isolation)
2 Buttons for programme selection
Step-by-step programme selection (upwards and down-
wards).
Switchover from TV to radio mode by pressing both buttons
simultaneously.
3 LED display (four character 7-segment display)
To display the selected programme slot and parameter set-
tings.
1 Mains input socket for 230 V/50 Hz
2 DATA socket
a) Connection facility for the URS 200 external infrared
sensor.
b) Connection for the UFP 10 Copy-Programmer for
read-in and read-out of the programme data
(function b is especially for service, for copying the
programme data).
3 VHF/UHF antenna input (signal is looped through).
4 VHF/UHF antenna output
(TV signal modulator-output, Ch. 38 is preset)
5 Satellite IF signal input A and
output of LNB supply voltage
6 Audio output, left and right channel (Cinch sockets)
7 Scart socket, TV connection
8 Scart socket, VCR connection
9 Scart socket, decoder connection
Remote control handset keys
Function 1:
Command set changeover
Function 2:
To blank out the video signal (in setup mode) This
function is to be used if the picture no longer synchro-
nises on adjustment and the picture scrolls.
Starts a timer
Last function. Allows you to switch back to the last pro-
gramme that was selected
Function 1:
Last function. Allows you to switch back to the last
programme that was selected
Function 2:
Displays the info menu
(active only if after pressing the key the
programme list is displayed.)
Function 1:
On/Off (Standby),
Attention: No mains isolation results!
Function 2:
Return from setup mode into normal operation
Function 1:
Calls up the TV programme list (or radio programme
list in radio mode).
Function 2:
Calls up menu for "Programme slot sorting (insertion),
swapping and copying“
(with press in succession)
Set timer, date and time
Function 1:
Selection of TV/SAT mode
Function 2:
Calls up the menu for video settings
(with press in succession)
Function 1:
Volume control
Function 2:
To alter settings data in setup mode
Function 1:
Steps through the programmes either up or down
Function 2:
Selection of individual menu entries in setup mode
Function 1:
Stores the chosen settings
Function 2:
Primary key for calling the separate setup menus (e.g.
video settings) Function 1:
Switchover to radio mode
Function 2:
Calls up the menu for radio settings
(with press in succession
Function 1:
Sound muting)
Function 2:
Calls up the menu for audio settings
(with press in succession)
to
Stereo/Mono- (2 channel) changeover
Numeric keys 0 - 9 for programme selection and fre-
quency entries
