ENGLISH
40
TECHNICAL SPECIFICATIONS – ENGINE 125/144/250 SX 2008
»
TIGHTENING TORQUES - ENGINE
Flange bolts - cylinder-head (125/144 SX)
M7 18 Nm
Flange bolts - cylinder-head (250 SX) M8 27 Nm
Nuts-cylinder base (125/144 SX) M8 30 Nm
Nuts-cylinder base (250 SX) M10 35 Nm
Flywheel collar nut M12x1 60 Nm
Nut for primary sprocket (125/144 SX) M16x1,5 links Loctite 243 + 130 Nm
Nut for primary sprocket (250 SX) M18x1,5 links Loctite 270 + 150 Nm
Nut for inner clutch hub (125/144 SX) M18x1,5 Loctite 243 + 130 Nm
Nut for inner clutch hub (250 SX) M18x1,5 Loctite 270 + 100 Nm
Bundschraube Kupplungsfeder M6 10 Nm
Oil drain plug M12x1,5 20 Nm
Oil drain plug (125/144 SX) clutch cover M10x1 15 Nm
Drain plug for water pump cover M10x1 15 Nm
Collar screw for water pump cover M6 Loctite 243 + 10 Nm
Water pump wheel M5 Loctite 243 + 6 Nm
Crankcase and clutch cover bolts M6 10 Nm
Collar screws for ignition cover M5 5 Nm
Collar screws for exhaust flange M5 6 Nm
Spark plug M14x1,25 25 Nm
Collar screws for ignition system M5 Loctite 243 + 6 Nm
Collar screw for kickstarter lever M8 Loctite 243 + 25 Nm
Collar screw für shifting lever M6 (10.9) Loctite 243 + 14 Nm
Other screws M 5 6 Nm
M 6 10 Nm
M 8 25 Nm
M 10 45 Nm
