KITCHENAID KBLO36FMX00 - Manual (Page 8)

REFRIGERATOR SHELF PARTS
8
For Model: KBLO36FMX00
(Etched Aluminum)
8198477
Illus. Part
No. No. DESCRIPTION
1 Slide, Freezer
Basket
2257355 Right Side
2257356 Left Side
2 2006475 Screw, 8−15 x 1.00
4 Spacer, Crisper
2256443 Right Side
2256442 Left Side
5 2179404 Rack, Wine
6 2221071 Egg Bin
7 Bracket, Freezer
Basket
2257327 Right Side
2257326 Left Side
12 2257562 Trim−Glass,
Side
13 2256474 Divider,
Crisper Pan
14 8533929 Screw
15 Slide, Crisper
2256440 Left Side
2256441 Right Side
18 2258973 Shelf (4)
19 2257563 Trim−Glass,
Side
21 2257561 Glass Shelf, Deli
29 2256375 Cripser Pan
Assembly
(Includes #30)
30 2256374 Front,
Crisper Pan
33 2257548 Front,
Deli Pan
37 2257560 Glass, Crisper
Shelf
38 2257564 Trim−Glass,
Rear
39 2257566 Trim−Glass,
Front
43 Slide, Deli
2257544 Left Side
2257545 Right Side
44 Spacer, Deli
2257531 Left Side
2257532 Right Side
47 2257535 Deli Pan
Assembly
(Includes #33)
48 2005410 Ladder, Shelf (4)
49 2006475 Screw,
