REFRIGERATOR LINER PARTS
4
For Models: KBLS20EVMS00
(Monochromatic Stainless)
W10234661
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 Y67003896 Bracket, Control
and Lights
3 W10209973 Overlay
4 W10185585 Module, Control
5 W10207861 Board, Control
6
C3680310 Switch, Light
7 67003897 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light (2)
10 Y12570701 Socket, Light (2)
11 67003900 Insert,
Damper Cover
12 67006602 Screw (2)
13 67003899 Cover, Damper
14 67006604 Insulation
15 W10127429 Control, Damper
(Includes Harness)
16 12002355 Thermistor
17 61006182 Union, Tube
18 67001668 Plate
19 W10153959 Tank, Water
20
12706909SP Dispenser
21 67006400 Screw
22 B8390302 Clip
23 67006524 Head, Water
Filter Assembly
24 12568001 Cover, Filter
25 13040210 Filter, Water
26 12664501 Plug, Filter
Bypass
27 12707303SP Plate, Switch
28 67006415 Screw
29 67005674 Cover
30 12575501 Switch, Limit
32 67002816 Clip, Water Tube
33 67003728 Guide, Water
Line
Following Parts Not Illustrated
67005644 Harness, Controls
(Refrigerator)
