15
PARTS LIST
MODEL NO.: RA3830SQD
RA3836SQD
(Optional Duct Cover)
NO. DESCRIPTION MODEL /SIZE PART NO.
RA3830SQD 10-03300-F 1 Hood Casing
RA3836SQD 10-03360-F
Air Chamber
Air Chamber (Top) C1-0102-0770F
Air Chamber (Side) C1-0101-0770F
2
A
B
C Air Chamber (Opening) C1-0241-0770FA
3 Motor (Right) C1-0301-0120-08A
4 Motor (Left) C1-0301-0120-07A
5 Impeller (Right) C1-0251-0092-02
6 Impeller (Left) C1-0251-0092-01
7 Impeller Plastic Cover C1-0251-0001
8 Oil Tunnel C1-0502-0201
9 Flat Head Screws (3/16” x 5/8”) C1-0704-0001
RA3830SQD B101-0330-09F 10 Bottom Casing
RA3836SQD B101-0336-09F
11 Halogen Light (12V 20W Max.) C1-0403-0101
12 Capacitor C1-0401-0120-01A
13 Transformer (Motor) C1-0402-A120-04
14 Transformer (Halogen Light) C1-0402-0120-40
15 Processor Board Box C1-0501-0102
16 Processor Board C1-0404-0401-B
17 Round Head Screw (TS 1/8” x 3/8”) C1-0708-0003
18 Control Unit C1-0501-0101
19 Control Board C1-0404-0401-A
Charcoal Filter Set RH-CF01
Charcoal Filter C1-0603-0302
Mesh Filter MF-0201 C1-0604-0201
Safety Screen C1-0602-0202
Oil Container (Round) C1-0503-0201
20
A
B
C
D
E
Safety Screen Screw C1-0705-0001
21 Plastic Plate C1-0507-0201
NO. DESCRIPTION MODEL /SIZE PART NO.
22 Hood-Mounting Bracket C1-0221-0330
23 Round Head Screw (TS 4 x 8 mm) C1-0708-0006
24 Duct Cover RA1020DC 12-02000-430
25 Duct Cover-Mounting Bracket C1-0203-0002
