STABI REFERENCE T U R N T A B L E 6 KUZMA
III. ASSEMBLY
1. Open box C and remove baseplate taking care not to knock motor pulleys. Place
in intended location for use.
2. Open box B, remove subchassis and lower gently into position on top of base plate.
Remove protection tape from shaft and check that the small ruby ball is in a central
position on top of the shaft.
3. From box A remove subplatter, belt and small oil bottle. Remove protection tape
from theunderneath of the subplatter.
4. From small oil bottle squeeze 35 drops of oil onto the top of the shaft. Oil will run
from top to fill lower well.
5. Gently lower subplatter onto shaft (NOTE: if at anytime it is necessary to remove
subplatter, be aware that a certain amount of oil will adhere to it). Airpressure will
slow motion ob subp.
6. Carefully put belt around both motor pulleys and subplatter to make a diamond
shape.
7. Remove platter from box D and place carefully on top of subplatter, mat uppermost.
8. Turning the adjustment knobs anticlockwise cause the subchassis to rise. If you
look
from the side between baseplate and subchassis you can see a line marked on each
suspension towers which is 7 mm above the baseplate. Adjust height of subchassis
by turning all 4 adjustment knobs so thar lowr edge of subchassis is level with
markings on all towers.
9. The cable for connecting power supply and turntable has five pin plugs which
should
be inserted and locked into connectors at rear of power supply and turntable.
10. Connect mains cable into mains and then switch on power supply at the rear of PS.
Red light should appear on front panel.
